Regarding the plastic granules, the drying method of the bottle flakes mainly includes dehydration drying, heating drying, etc., and different drying methods are adopted for the characteristics of different plastic materials. Vertical type Dryer Mixer with heating system is very good way of drying for plastic flakes and pellets.

In view of the use of plastic pellets for film blowing, extrusion, etc., customers generally worry that the water content of plastic pellets is too high, so that there will be a series of problems such as “fisheye” and “foaming” in the production of finished products, and due to plastic recycling. In the process of granules, due to the instability of the raw material source, the color of the plastic granules is not uniform, which causes buyers to worry about the quality of the granules, color and other factors are unstable, affecting the transaction process and the price of the granules.

This plastic lifting mixing dryer completely solves these two problems. The internal lifting screw can send the bottom particles to the top to be sprayed out. After hot air drying, the moisture content of the particles is effectively reduced, and the plastic particles are continuously improved. Effectively mixed, so that the mixed particles are uniform in color and stable in quality to achieve the desired effect.

After continuous research and improvement by our company, we have designed the granulation scheme according to the actual material conditions of the customers. From the waste raw materials to the finished products, we always adhere to high efficiency, energy saving and stability. Solve problems for customers and achieve mutual benefit and win-win.

We draw on foreign advanced equipment technology, visit customers’ factories, listen carefully to customers’ actual operating experience, digest and absorb the advanced concepts of the recycling industry, and combine the actual development of the waste plastics industry to continuously improve the design of equipment components, which can meet the domestic and international recycling plastics industry. Requirements and ability to meet the environmental requirements of the local recycling industry.

At the same time, our company also produces plastic recycling washing line, plastic pelletizing machine, and related auxiliary equipment. Our company’s products can meet EU standards, and strictly in accordance with national standards. We always adhere to the concept of high efficiency, stability and energy saving. By tailoring suitable production solutions for our customers, we can help our customers turn waste into treasure, create profits and achieve mutual benefit.

The plastic Vertical type Dryer Mixer with heating system produced by our company has many different output, 500kg/h, 1000kg/h, 2000kg/h, 3000kg/h, 4000kg/h, please refer to the detailed parameters.

If you have any questions, please don’t hesitate to contact us. We’d like help you and reach win-win situation with you!

Volume 1000L 2000L 4000L 6000L 8000L
Capacity(kg/h) 500 1000 2000 3000 4000
Lift Screw Motor(kw) 2.2 3 4 5.5 5.5
Lift Screw Diameter(mm) 219 219 273 273 273
Lift Screw Blade Thickness (mm) 3 3 3 3 3
Principal Axis Size(mm) 60×4 60×4 60×4 60×4 60×4
Wall Thickness(mm) 2 2 2.5 3 3
Center Bearing Bracket Size(mm) 32 32 38 38 38
Lift Screw Speed(rpm) 320 320 320 320 320
Blow Motor(kw) 1.1 1.5 2.2 3 3
Heating Power(kw) 24 36 42 48 48
Overall Size(Dia x H)(mm)  Ø1100×2450 Ø1300×2750 Ø1600×3400 Ø1910×3600 Ø2100×4000
Support Square Size(mm) 80x80x3 100x100x3 120x120x4 120x120x4 150x150x4
Delivery Time Two Weeks Two Weeks Two Weeks Two Weeks Two Weeks
Warranty One Year One Year One Year One Year One Year
